Thales Triode 220V Radio Frequency Dryer Machine Heating And Drying Machine

Name: Thales Triode 220V Radio Frequency Dryer Machine Heating And Drying Machine
Brand: Alees
Price: 5000 USD

Best Thales Triode 220V Radio Frequency Dryer Machine Heating And Drying Machine wholesale

Brand Name : Alees

Model Number : AS01-85KW

Certification : CE

Place of Origin : China

MOQ : 1

Price : USD5000-250000

Packaging Details : Wooden Case/Plastic Film

Delivery Time : 6-9 weeks

Supply Ability : 50 sets per month

Material : Stainless Steel

Temperature Range : 50°C - 200°C

Voltage : 220V

Frequency : 50Hz

Power : 1000W

Contact Now

Introduction

AS01-85KW/170KW is suitable for the drying of yarn packages after dyeing and hydro extraction.

Technical Specification and standards

-Electrical supply voltage: 380V±5%

-Electrical supply Frequency: 50HZ

-Operating frequency: 27.12MHZ±0.6%

-Input power: 142KVA

-Output power: 85KW

-Conveyor belt operating speed: 2.5M/H-107M/H

-Cooling system: Water cooling;air cooling

-Water circulation: 2.5m³/h

-Evaporative capacity: 1.2-1.3kg(water)/kw(RF)h

-Steam Consumption: 20-25kg/h Pressure≥0.4Mpa

-Max product height: 260mm

-Max loading width: 1650mm

-External dimensions: 9m*2.4m(3.1mmax)*3.3m

-weight: 4500kg

Technical Specification and standards

Model	AS01-85KW
Electrical supply voltage	380V±5%
Electrical supply Frequency	50HZ
Operating frequency	27.12MHZ±0.6%
Input power	142KVA
Output power	85KW
Conveyor belt operating speed	2.5M/H-107M/H
Cooling system	Water cooling;air cooling
Water circulation	2.5m³/h
Evaporative capacity	1.2-1.3kg(water)/kw(RF)h
Steam Consumption	20-25kg/h Pressure≥0.4Mpa
Max product height	260mm
Max loading width	1650mm
External dimensions	9m2.4m(3.1mmax)3.3m
weight	4500kg

Production Capacity

Synthetics	900-1000(kg/h)
Wool&cotton blends	350-400(kg/h)
Cotton&viscose	200-250(kg/h)
